Sample thumbnails of tubing charts

Tubing Charts, All Standard Tube Sizes, Tube Gauges, and Custom Tube Sizes...

In the market for custom metal tubing? Four Slide Products has metal tube size charts for an array of stainless steel, hypodermic, half gages, metric, and fractional tube sizes to help navigate available standard and custom metal tubing sizes — view our:

Stainless Steel Tubing Chart »

Hypodermic Stainless Steel Tubing Chart »

Fractional and Metric Tubing Chart »
Sample sizes of cut tubing from Four Slide Products

We Provide Custom Contract Tube Cutting
and Fabrication

We are a contract manufacturer of shear-cut tubular parts. Any workable alloy, tube sizes 0.015" to 0.625" and larger can be cut to lengths from 0.010" ± 0.001" with no distortion of outside or inside diameter and no square edges. Our cutting process is efficient and extremely accurate leaving no wasted scrap. Our process can save you up to 50% on material costs. Below we provide tubing charts that were created based on the most frequently requested sizes.

"I can and will say, none of our previous cut tube orders were as trouble-free as our first order with Four Slide Products."

-Duane D. Riha, Legacy Technologies, Inc.

View a Free Stainless Steel Tubing Chart

Get a free stainless steel tubing chart. It is a great reference to keep the ordering process simple. The tubing chart contains the stainless steel tubing sizes in standard gauges 7 to 25 and half-gauges 3.5 to 25.5. The chart breaks down the outer diameter and inner diameter range of light and heavy wall, hard temper, type 304- and 316-grade stainless steel.

VIEW CHART »

View a Hypodermic Stainless Steel Tubing Chart

Get a free printable hypodermic stainless steel tubing chart that provides the various wall dimensions. The most common tubing is hard tempered; however, we also offer intermediate tempers and annealed tubing. The charts show 304- and 316-grade tubing with gauges from 3 to 29.

VIEW CHART »

View a Fractional and Metric Tubing Chart

We also offer a fractional and metric tubing chart for your convenience. This chart provides the outer diameter dimensions for an array of wall thicknesses in fractional and metric measurements. Typical thicknesses are from 0.010" to 0.035" and are also provided in millimeters.

VIEW CHART »
Thumbnail of Custom Cut Tubing Sizes

Need custom sizes for fractional
and gauged tubing?

We provide custom tubing for many of our clients. We have engineers and fabrication machines that can adjust outer diameters, wall thicknesses, and inner diameters and can provide part bending/forming solutions for your tubing needs. So, if you don't see what you are looking for, contact us now for more information about custom tube sizes »

ISO Compliant Company

Family Owned Since 1985

Proudly Made in the U.S.A.

"10,000 cut tube pieces "awesome job the first time"
- Raytheon
